From Platform to Mission: We Are a Vertical Mission System Supplier
Traditional UAV vendors only sell “flight platforms” — customers must source and integrate payloads, AI models, and communication systems on their own. We deliver “mission-ready integrated systems,” not just aircraft.
UAV Flight Platforms
Covering heavy-lift, long-endurance, and high-speed models to fit diverse mission scenarios.
Edge AI Smart Payloads
Built-in AIVO and XEdgAI, empowering drones with real-time perception and autonomous decision-making.
Mission System Integration
Anti-jamming communications, GCS ground control, and full mission equipment integration.
Key Differentiator
Non-red supply chain options for critical components, ensuring security for defense and sensitive missions.
One-stop Service
From requirements definition, system design, and AI model deployment to mission validation — we accompany our customers all the way.
Complete UAV Lineup Covering Diverse Mission Scenarios
| Model | Wheelbase | Body Weight | Max Takeoff Weight | Flight Time (Full Load) | Max Horizontal Speed | Positioning |
|---|---|---|---|---|---|---|
| Goshawk | 1400 mm | 15.1 kg | 41.5 kg | 10 min | 10 m/s | Heavy-lift / Firefighting / Agri-spray |
| Albatross | 1400 mm | ≈15 kg | ≈41.5 kg | 10 min | 10 m/s | Heavy-lift Mission |
| Buzzard | 1050 mm | 6.5 kg | 16 kg | 17 min | 12 m/s | Medium Multi-purpose |
| Kite | 650 mm | 2.5 kg | 5 kg | 15 min | 15 m/s | Light Reconnaissance |
| Kestrel | 350 mm | 750 g | 3.25 kg | 8 min | 9 m/s | Small Reconnaissance |
| Sparrowhawk | 450 mm | 1.05 kg | 3.55 kg | 10 min | 9 m/s | Light Mission |
| Merlin | 435 mm | 990 g | — | 30 min | 9 m/s | Long-endurance Reconnaissance |
| Swift | — | 450 g | 600 g | 15 min | 30 m/s | High-speed / FPV |
Goshawk — Heavy Payload, High Altitude, Modular Heavy-lift Platform
- Dimensions: unfolded 1900×1900×660 mm / folded 1000×1000×660 mm
- Propulsion: 1400 mm wheelbase, 36-inch propellers for stable lift
- Payload: body weight 15.1 kg, max takeoff weight 41.5 kg, 20-liter payload volume
- Performance: altitude up to 3,000 m, max horizontal speed 10 m/s
- Resilience: IP45 waterproof, wind resistance Level 5 (10.7 m/s)
- Comms & power: >3 km communication range, 44.4–50.4 V
- Validated: high-altitude firefighting with eco-friendly extinguishing-liquid spray system
Merlin — Long-endurance Platform Optimized for AI Reconnaissance
- Compact & portable: unfolded 475×545×105 mm, only 990 g
- Flight performance: max speed 9 m/s, Level 5 wind resistance
- Flight modes: Mission, Altitude-hold, GPS, and Landing
- Ideal Edge AI carrier for high-precision smart reconnaissance and real-time target recognition
- Data-only transmission: up to 30 min endurance
- C10 gimbal (1,055 g total): 27 min with data & video transmission
- C12 gimbal (1,110 g total): 25 min with data & video transmission
AIVO — Evolving UAVs from “Remote Control” to “Autonomous Missions”
AIVO (AI Visual Omniscient) is an AI vision comprehensive solution platform, supporting flexible deployment on both server-side and Edge AI.
Diverse Application Scenarios
Widely applied in disaster search & rescue, precision spraying, security patrol, and smart city domains, providing real-time and precise visual intelligence.
Validated in High-security Environments
Successfully deployed in high-security facilities including military bases, airports, and chemical plants, building highly reliable virtual fences and monitoring systems.
Core Technology Advantage
Proprietary algorithms achieve AI model compression — retaining high recognition accuracy while perfectly fitting the computing limits of UAV edge devices.
XEdgAI — Deploy AI to UAV Edge Devices in Just a Few Steps
XEdgAI (Express Edge AI) is a full-stack AI platform built for edge deployment: low-latency real-time computing, flexible cross-platform hardware support, and high customizability.
Fragmented Workflow
→ Unified full-stack platform
Vendor Lock-in
→ Hardware freedom
High Technical Barrier
→ Simplified deployment
Model Incompatibility
→ Model-aware optimization
Choose the function, not the model: tell the system your task (e.g. object tracking) and it automatically matches the best model and hardware, with smart notifications via cloud or local server.
Integration Architecture: From Flight Platform to Smart Mission System
Communication Link
High-reliability, low-latency data transmission: anti-jamming comms (SDR), HD video transmission, swarm mesh networking.
Mission System
Global situational awareness and command center: GCS ground control, real-time data & analytics, mission planning & autonomy.
AI Payload
Edge computing capability: AIVO vision models, XEdgAI deployment engine, Edge AI hardware (Jetson / QCS6490).
Flight Platform
Stable, reliable aerial vehicles, flexibly configured per mission: Goshawk (heavy-lift), Buzzard (medium), Kite (light), Merlin (long-endurance).
Integration value: customers only need to define the mission objective — we deliver a complete, executable vertical mission system.
Case Studies
Large UAV High-altitude Firefighting Mission System
- Challenge: traditional firefighting is limited by terrain and response time — fire trucks cannot access steep mountains and large aircraft take long to dispatch.
- Solution: Goshawk heavy-lift platform integrated with an eco-friendly fire-extinguishing liquid spray system for low-altitude precision spraying.
- System specs: 20-liter payload capacity, 3,000 m flight altitude, IP45 waterproof rating.
- Modular retrofit: standard agricultural spray system converted for firefighting, enabling rapid mission reconfiguration.
- Validation: system integration and functional verification completed.
- Demonstrated capability: full-process delivery from platform selection and payload integration to system retrofit and mission validation.
Integrated Tactical Quadcopter System
- Challenge: defense customers require tactical quadcopters capable of autonomous reconnaissance in complex, high-threat environments.
- Solution: tactical quadcopter platform integrated with Edge AI and military-grade secure communications.
- Edge AI: AIVO deployed on edge devices for real-time detection, target tracking, and autonomous decision support.
- System specs: high-speed maneuverability, encrypted data links, robust anti-jamming capability, rapid-deployment design.
- Validation: integrated capabilities demonstrated for defense clients.
Non-red Supply Chain for Critical Components
Per the customer's security level, we provide customized UAV systems that fully exclude red-supply-chain components — for defense, government, and sensitive commercial missions.
Flight Control System
NDAA-compliant, high-reliability flight controllers developed in Europe, the U.S., or Taiwan; secure firmware with no unauthorized data transmission and anti-spoofing GPS.
Communication & Video Link
Non-red RF modules and transceivers, AES-256 encrypted C2 links, secure anti-jamming SDR options.
Edge AI Computing
Trusted hardware platforms (NVIDIA, Axelera, Intel, Qualcomm) ensuring secure AI computing power that meets the highest information-security standards.
Optical & Sensor Payloads
High-end sensors, thermal imagers, and precision gimbals made in Taiwan and allied countries — eliminating backdoor and data-leak risks at the hardware source.
End-to-End Cooperation Model: From Requirements to Mission Delivery
Requirements Definition
Confirm mission objectives, define payload specs, assess environmental constraints.
System Design
Flight platform selection, AI model planning, communication architecture design.
Integration & Development
Hardware assembly, XEdgAI edge deployment, GCS configuration.
Testing & Validation
Flight testing, AI inference validation, environmental adaptability tests.
Mission Delivery
Education & training, system handover, ongoing technical support.
Full Specifications
| Specification | Goshawk | Kestrel | Buzzard | Kite | Swift | Merlin | Albatross | Sparrowhawk |
|---|---|---|---|---|---|---|---|---|
| Working Dimensions (with propellers, L×W×H mm) | 1900 × 1900 × 660 | 420 × 420 × 65 | 1355 × 1360 × 625 | 872 × 870 × 115 | — | 475 × 545 × 105 | 1900 × 1900 × 660 | 560 × 560 × 65 |
| Folded Dimensions (with propellers, L×W×H mm) | 1000 × 1000 × 660 | — | 930 × 930 × 625 | — | — | 227 × 126 × 105 | 1000 × 1000 × 660 | — |
| Wheelbase | 1,400 mm | 350 mm | 1,050 mm | 650 mm | — | 435 mm | 1,400 mm | 450 mm |
| Propeller Size | 36 in | 7 in | 24 in | 15 in | 4 in | 8 in | 36 in | 10 in |
| Frame Weight (without payload) | 15,100 g | 750 g | 6.5 kg | 2.5 kg | 450 g | 990 g | 15 kg (approx.) | 1.05 kg |
| Flight Time (approx.) | — | 32 min | 35 min | 40 min | — | 30 min (data transmission only) | 10 min (full weight) | 36 min |
| Max Takeoff Weight (approx.) | 41,500 g | 3.25 kg | 16 kg | 5 kg | 600 g | — | 41.5 kg (approx.) | 3.55 kg |
| Full Load Flight Time (outdoor hover) | 10 min (safe voltage 42 V) | 8 min | 17 min | 15 min | 15 min | — | 10 min (full weight) | 10 min |
| Full Load Recommended Flight Time (outdoor hover) | — | 7 min | 16 min | 12 min | 12 min | — | — | 8 min |
| Max Horizontal Speed | 10 m/s | 9 m/s | 12 m/s | 15 m/s | 30 m/s | 9 m/s | 10 m/s | 9 m/s |
| Max Vertical Speed | 3 m/s | 3 m/s | 3 m/s | 3 m/s | 6 m/s | 3 m/s | 3 m/s | 3 m/s |
| Operating Temperature | 0°C ~ 50°C | -20°C ~ 50°C | -20°C ~ 50°C | -20°C ~ 50°C | -20°C ~ 50°C | -20°C ~ 50°C | -20°C ~ 50°C | -20°C ~ 50°C |
| Wind Resistance | Level 5 (10.7 m/s) | Level 5 (10.7 m/s) | Level 5 (10.7 m/s) | Level 5 (10.7 m/s) | Level 5 (10.7 m/s) | Level 5 (10.7 m/s) | Level 5 (10.7 m/s) | Level 5 (10.7 m/s) |
| Max Tilt Angle | 15° | 30° | 25° | 30° | 30° | 25° | 15° | 30° |
| Operating Mode | — | Manual, Acrobatic | Mission, Altitude-hold, GPS, Landing | Manual | Manual | Mission, Altitude-hold, GPS, Landing | Mission, Altitude-hold, GPS, Landing | Manual, Acrobatic |
| Nominal Voltage (V) | 44.4 ~ 50.4 | 22.2 | 44.4 | 22.2 | 22.2 | 16.8 | 44.4 | 22.2 |
| Battery Type | Li-ion | Li-ion | Li-ion | Li-ion | Li-ion | Li-ion | Li-ion | Li-ion |
| Rated Capacity (mAh) | 20,000 | 10,000 (approx. 900 g) | 20,000 × 2 (approx. 2,250 g × 2) | 10,000 (approx. 900 g) | 2,200 | 5,000 | 20,000 × 2 (approx. 2,250 g × 2) | 10,000 (approx. 900 g) |
| Payload Capacity | 20 L | — | — | — | — | — | — | — |
| Waterproof Rating | IP45 | — | — | — | — | — | — | — |
| Max Altitude | 3,000 m | — | — | — | — | — | — | — |
| Frame Weight (with C10 Gimbal) | — | — | — | — | — | 1,055 g | — | — |
| Flight Time with C10 (outdoor hover) | — | — | — | — | — | 27 min (data & video transmission on) | — | — |
| Frame Weight (with C12 Gimbal) | — | — | — | — | — | 1,110 g | — | — |
| Flight Time with C12 (outdoor hover) | — | — | — | — | — | 25 min (data & video transmission on) | — | — |
Remote control / communication / camera: 2.4 GHz & 5.8 GHz digital link, communication range >3 km (no interference), camera 1280×720 @ 30 fps, with GPS, altimeter and compass flight indicators.
We Don't Just Sell Drones — We Deliver Drones That Complete Your Mission
Vertical mission system supplier | Full-stack software-hardware integration | Non-red supply chain for critical components
